VRS4

Team with Deltech to provide a deeper and more engaging experience with your Radio audience.

Migration from Digital to Visual Radio has never been easier!

The VRS4 provides automated audio microphone / camera switching with manual override.

The system chooses the right shot according to the speaking detection.

In real time, Camera pre-sets can be automatically recalled and switched.

AoIP channel decoding & detection for active speaker broadcast.

RECORD, LIVE STREAM, PODCAST

Broadcast your Visual Radio show to social media platforms and engage a wider audience. We offer solutions for interactivity and social media networks for the ultimate viewer experience.

Today’s “listener” is consuming media on their mobile devices and Visual content is the solution to attract and keep your audience on your radio show.

Social Media Ingest

Engage your audience with the moderation and social media messages integration.
View a live Twitter feed based on Search, Home Timeline, User Timeline or Favorites.
View Facebook comments.
View Instagram Hashtags and User Timelines.
View YouTube Live chat comments on your YouTube live streams.
View messages from any IRC chatroom.
Content can be viewed and approved via any web browser including Tablets and Smart Phones

vMix Call makes it easy to add remote guests to your vMix production. With only a web browser and webcam your guest can connect into your live show with HD video and high-quality audio from anywhere in the world

Various angle of shots

Each microphone can be covered by different cameras and shot angles.

You define shots for each microphone.

Thanks to the PTZ Cameras support, you can manage over 100 different shots by cameras.

Each shot is independently accessible.

Visual Radio add-on to your radio production requires no additional staff. Engage your audience at a higher level with a compelling, rich and entertaining experience.

Contact DeltechCGI

We offer a wide range of “ALL IP,” SDI or Hybrid solutions.

The VRS4 Standard package includes:

↦ 4RU Server Unit
↦ 23 HD Touchscreen
↦ Joystick

↦ IP Box: no HD-SDI or HDMI inputs/outputs, only IP.
↦ 4 Dual Box: 4 x HD-SDI/HDMI inputs + 1 x HD-SDI and HDMI output.
↦ Optional Production Keyboard / Joystick.

With supported IP camera, you can add more cameras than the number of HD-SDI inputs on the box.

Deltech provided Compatible Cameras

Specification

Dimension (D x W x H) 546 x 430 x 176 (mm), 21.5” x 16.9” x 6.9”
Drive Bay Exposed: 3 x 5.25”, 1 x 3.5”, 1 x Slim ODD; Internal: 4 x 3.5
PSU Form Factor PS/2 Single or Mini-redundant
Indicators 1 x Power Status, 1 x HDD Activity, 2x LAN Activity
Front Control Power On/Off, Alarm Mute, System Reset, 2 x USB2.0/USB3.0(Option)
Gross Weight 15.5 kg
Cubic Feet 4.03
Container Info 20’: 245, 40’: 524, 40’H: 592

Feel free to contact us if you have any questions
